oem Dahua

Videoregistratore hdcvi dvr xvr 8MP 16Ch canali

Videoregistratore hdcvi dvr xvr 8MP 16Ch canali

€349,00
€349,00
Sale Sold out
Tax included. Shipping calculated at checkout.

Colore: Nero

Tipo: videoregistratore

Modello: XVR5216AN-4KL-X

Marca: oem Dahua

MPN: CVR16PRO3

Caratteristiche: Digitale

Garanzia produttore: 4 anni

Contattaci per l'acquisto di quantità maggiori rispetto alla disponibilità.

Caratteristiche del prodotto:

  • Registra 16 canali fino a 8,0 MP (3840 x 2160) a 7 fps
  • Compressione video ad alta efficienza H.265
  • 2 porte SATA fino a 10 TB, capacità HDD massima di 20 TB
  • Supporto per ingressi video HDCVI, analogici e IP
  • Aggiungi 8 canali IP aggiuntivi fino a 8,0 MP di risoluzione
  • Distanza di trasmissione video fino a 700 m su cavo coassiale
  • Visualizzazione remota per dispositivi iOS e Android
  • Uscita video simultanea HDMI (fino a 4K, 3840 x 2160) e VGA
  • Backup tramite dispositivo USB esterno o rete locale
  • La ventola intelligente e silenziosa si regola automaticamente con la temperatura della CPU

Specifications

General
Main Processor
Embedded Processor
Operating System
Embedded LINUX
Video Input
16 channel BNC
Audio In/Out
1 channel input / 1 channel output
Two-way Talk
Reuse channel 1 audio input/output
Internal HDD
2 x SATA ports up to 10TB, max. 20TB HDD capacity
USB Interface
2 ports: 1x USB2.0, 1x USB3.0
Auxiliary Inputs
1 x RS485 port (for PTZ)
Power Supply
12VDC/5A
Power Consumption
<20W
Operating Environment
-10°C ~ +55°C (+14°F ~ +131°F), 10%~ 90% RH
Dimensions
375mm×287mm×53mm
Rackmountable
No
Rackmount Unit
1RU
Weight
1.7kg (without HDD)
Cross Compatibility
Supported Video Inputs
HDCVI / HDTVI / AHD / Composite / IP
Coax Input Support
16 channels
IP Input Support
24 channels (16 substitute, 8 additional)
IP Input Max. Resolution
8.0MP
IP Input Max. Bandwidth
96Mbps
Display
Video Output
1 HDMI / 1 VGA
Display Resolution
3840×2160 / 2560×1440 / 1920×1080 / 1280×1024 / 1280×720
Display Split
1/4/8/9/16/25
OSD
Camera title, time, video loss, camera lock, MD & recording
Recording
Maximum Resolution
8.0MP (3840 x 2160) / 4.0MP (2560 x 1440) / 1080p (1920 x 1080)
Frame Rate (Main)
8.0MP (1~7fps) / 5.0MP (1~12fps) / 4.0MP & 3.0MP (1~15fps) / 1080p (1~25fps)
Frame Rate (Sub)
D1 (1~25fps)
Frame Rate (Third)
N/A
Video Compression
H.265+/ H.265 / H.264+ / H.264
Bit Rate
32Kbps ~ 6144Kbps Per Channel
Record Modes
Manual, Schedule (General, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
Record Interval
1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
Features
Alarm Input / Output
N/A
Trigger Events
Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
Video Detection
Motion Detection, MD Zones: 396 (22 × 18), Video Loss,Tampering and Diagnosis
Playback Sync
1 / 4 / 9 / 16
Search Modes
Time /Date, Alarm, MD and Exact Search (accurate to second)
Intelligent Functions
Channel 1(IVS Only)Face Detection, Tripwire, Abandoned/Missing Object
Backup Modes
USB Device / Internal SATA burner / Network
Network
Ethernet
1x RJ-45 port (1000M)
Network Functions
HTTP, HTTPS, TCP/IP, IPv4/IPv6, Wi-Fi, 3G/4G, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P, IP Search
Max. User Access
128 users
Remote View
iOS (iPhone, iPad); Android devices
Warranty (Years)
4

Shipping Weight and Dimensions

Includes product packaging

Width
140 mm
Height
435 mm
Depth
360 mm
Weight
3.00 kg
