Oem Dahua
Videoregistratore videosorveglianza 16 canali, 1080p 2mp, HDCVI
Videoregistratore videosorveglianza 16 canali, 1080p 2mp, HDCVI
Prezzo di listino
€149,00
Prezzo di listino
Prezzo scontato
€149,00
Prezzo unitario
per
Imposte incluse.
Spese di spedizione calcolate al check-out.
Impossibile caricare la disponibilità di ritiro
Tipo: Videoregistratore
Marca: Oem Dahua
Modello: DVR
Contattaci per l'acquisto di quantità maggiori rispetto alla disponibilità.Caratteristiche del prodotto:• Registra una risoluzione di 2,0 MP (1920 x 1080) fino a 25 fps
• Supporto per ingressi video HDCVI, analogici e IP
• Distanza di trasmissione video fino a 700 m su cavo coassiale
• 8 porte SATA fino a 10 TB, capacità massima di 80 TB HDD
• Configura la visualizzazione remota iOS/Android in pochi secondi tramite codice QR
• Uscita video simultanea HDMI, VGA e TV (BNC)
• Uscita video simultanea HDMI, VGA e TV (BNC)
• Backup tramite dispositivo USB esterno, rete locale o DVD-RW
Specifications
General
Main Processor
Embedded processor
Operating System
Embedded Linux OS
Video Input
16 channel BNC
Audio In/Out
16 channel input / 1 channel output
Two-way Talk
1 channel input/output BNC
Internal HDD
8 x SATA ports up to 10TB, max. 80TB HDD capacity
USB Interface
4 x USB2.0 ports (2 Rear)
Auxiliary Inputs
1 x RS232 port (PC comm. & keyboard) / 1 x RS485 (for PTZ)
Power Supply
100 ~ 240VAC 50/60 Hz
Power Consumption
40W (without HDD)
Operating Environment
-10 ~ +55°C / 10 ~ 90%RH / 86~106kpa
Dimensions
440 x 460 x 89 (mm) / 2U Rackmount
Rackmountable
Rackmount Unit
Weight
6.5kg (without HDD)
Cross Compatibility
Supported Video Inputs
Coax Input Support
IP Input Support
IP Input Max. Resolution
IP Input Max. Bandwidth
Display
Video Output
2 HDMI / 1 VGA / 1 TV (BNC)
Display Resolution
1920 x 1080 / 1280 x 1024 / 1280 x 720 / 1024 x 768
Display Split
1 / 4 / 8 / 9 / 16
OSD
Camera title, Time, Video loss, Camera lock, Motion detection
Recording
Maximum Resolution
1080p (1920 x 1080) / 720p (1280 x 720)
Frame Rate (Main)
1080p (1~12fps), 960H (1~25fps)
Frame Rate (Sub)
D1 (1~25fps)
Frame Rate (Third)
N/A
Video Compression
H.264 / G.711
Bit Rate
48~8192Kb/s
Record Modes
Manual / Schedule (Regular [Continuous], MD, Alarm) / Stop
Record Interval
1~120 min (default: 60 min) / Pre: 1~30s / Post: 10~300s
Features
Alarm Input / Output
16 channel input / 6 relay output
Trigger Events
Recording; PTZ; tour; alarm; push video notification; email notification; FTP upload; internal buzzer; and screen tip overlay
Video Detection
Motion detection (zones: 396 [22 × 18]) / Video loss / Camera blank
Playback Sync
1 / 4 / 8 / 16
Search Modes
Time/Date; Alarm; Motion detection; Exact search (to the second); Smart Search
Intelligent Functions
Backup Modes
USB Device / eSATA Devic e/ Internal SATA burner (optional) / Network
Network
Ethernet
2 RJ-45 ports (10/100M/1000M)
Network Functions
HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, Alarm Server
Max. User Access
128 users
Remote View
iOS (iPhone, iPad); Android devices, Windows Phone
Other
Camera Configurations
Coaxial: 16 channels up to 960H/25fps (analogue) 1080p/12fps (HDCVI) / IP: 2 channels up to 1080p/12fps (substitutes coaxial)
External HDD
1 eSATA port, up to 16TB
Interoperability
ONVIF 2.4.1, CGI Conformant
Warranty (Years)
4
